Model
SN-510
SN-510 Master Controller
SN-510Façade Lighting / Controllers & Control Systems
Master controller for pixel and DMX lighting that runs from a PC or from effect files on an SD card, and drives EN-series slave controllers over Ethernet. One unit controls up to 400,000 channels or 154 controllers.
Features
- PC control or SD-card playback, switchable
- Drives EN-series controllers on the same link; effects change by swapping SD-card files
- Up to 400,000 channels or 154 controllers (80 or fewer recommended)
- RJ45 Ethernet interface
- Optional time control, cascade sync, GPS and BTS satellite sync, DMX control
- Animation software included
- AC 100–240V input, under 10W
Specifications
- Model
- SN-510
- Input Voltage
- AC 100–240V
- Working Power
- < 10W
- Cascade Signal
- Optocoupler (SN cascade); SW Ethernet protocol (PC–SN, SN–EN)
- Network Interface
- RJ45 Ethernet
- Loading
- 400,000 channels (printed "40W channels")
- Output Control
- Up to 154 controllers (80 or fewer recommended)
- Transmission Distance
- 100 m between controllers over UTP; up to 5 km with an optical-fibre converter
- Housing
- Iron
- Working Temperature
- -15°C to 60°C
- Relative Humidity
- ≤ 50% RH
- IP Rating
- IP 20
- Net Weight
- 1300 g
Specifications from ACON catalogues and datasheets. Subject to change — confirm with ACON before specifying.
