AI-WW-24-EA / AI-WW-36-EA
AI-WW-EA
Linear wall washer with a 20° x 15° beam in 2700K or 3000K, in 24W and 36W versions of 1000 mm. The drawing shows ground and wall mounting on a tilting bracket.
- Wattage
- 24W · 36W
- Protection
- IP 66
- CCT
- 2700K / 3000K
- Beam
- 20° x 15°
Features
- 20° x 15° beam
- 2700K or 3000K
- 24W and 36W versions, 1000 mm long
- Ground or wall mounting
- Tilting bracket, drawn at 90° and 100°
- 230V or 24V input
- IK 08 and IP 66
Specifications
- Length
- 1000 mm
- Input Voltage
- 230V / 24V
- CCT
- 2700K / 3000K
- Beam Angle
- 20° x 15°
- IK Rating
- IK 08
- IP Rating
- IP 66
- Dimensions
- 49 x 55.5 mm body; 108.8 mm high with bracket
Models
2 modelsValues common to every model are listed under Specifications.
Specifications from ACON catalogues and datasheets. Subject to change — confirm with ACON before specifying.
